| Function | Frequency | Insertion Loss | Isolation | IP3 | RON | Power (CW, max) | Switch Speed | Power Consumption | Lifetime | Controller | VBB or VIN VDD | Packaging | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MM5230 | SP4T (normal-port mode) SPST (super-port mode) (1) | DC–18 GHz DC–26 GHz | 0.1-1.3 dB 0.1-1.4 dB | 25dB @ 6 GHz 42dB @ 6 GHz | 95 dBm | 0.6Ω | 25 W | <10 µs | 0.08 mW | >3B cycles | Direct Drive | 89 V | 2.5 x 2.5 mm WL-CSP |
| MM5130 | SP4T (normal-port mode) SPST (super-port mode) (1) | DC–18 GHz DC–26 GHz | 0.1-1.3 dB 0.1-1.0 dB | 25dB @ 6 GHz 45dB @ 6 GHz | 95 dBm | 1.2Ω | 25 W | <10 µs | 0.08 mW | >3B cycles | Direct Drive | 89 V | 2.5 x 2.5 mm WL-CSP |
| MM5120 | SP4T | DC–18 GHz | 0.1-1.5 dB | 26 dB @ 6 GHz | 90 dBm | 1.0Ω | 25 W | <15 µs | <15 mW | >3B cycles | SPI/GPIO | 5 V 3.3 V | 5.2 x 4.2 mm LGA |
| MM5140 | SP4T | DC-8 GHz | 0.1-0.5 dB | 32 dB @ 3 GHz | 90 dBm | 1.0Ω | 25 W | <15 µs | <15 mW | >3B cycles | SPI/GPIO | 5 V 3.3 V | 5.2 x 4.2 mm LGA |
(1) Refer to datasheet for other configurations.
The MM5230 device is a high-power and wide frequency range SP4T micro-mechanical switch.
Menlo Micro has developed a new Ideal Switch® fabrication process and applied it to DC and wideband RF/microwave switch applications.
This innovative technology enables highly reliable switches capable of 25 W power handling.
The MM5230 provides ultra-low insertion loss and superior linearity as an SP4T from DC to 18 GHz, and greater than 3 billion switching cycles
Access additional design information on the
Menlo Support Portal >
Top view
Bottom view
The MM5230 on an evaluation kit board.
• DC to 26 GHz Frequency Range
• 25 W (CW), 150 W (Pulsed) Max Power Handling
• Low On-State Insertion Loss: 0.3 dB @ 6.0 GHz
• High Linearity, IIP3 95 dBm Typical
• 25 dB Isolation @ 6.0 GHz / 42 dB Super-Port Mode
• High Reliability >3 Billion Switching Operations
• 2.5 mm x 2.5 mm WLCSP Package (200 µm Solder Ball)
• Defense and Aerospace
• Medical Equipment
• Test and Measurement
• Wireless Infrastructure
• Switched Filter Banks and Tunable Filters
• High Power RF Front Ends
• Antenna Tuning
• Low-Loss Switch Matrices & EM Relay Replacement
 | EM (SMT) SPDT | EM (Coax) SPDT | Key Benefits | |
|---|---|---|---|---|
| Max Frequency | 26 GHz | 6 GHz | 18 GHz | |
| Insertion Loss | 0.3 dB @ 6GHz | 0.8 dB @ 6GHz | 0.2 dB @ 6GHz | |
| Isolation | 42 dB @ 6GHz | 25 dB | 70 dB @ 6GHz | |
| Power Handling | 25 W (CW) >150 W (Pulsed) | 50 W | 50 W - 100 W | |
| Linearity (IP3) | 95 dBm | 62 dBm | >1000x improvement | |
| Power Consumption | <0.08 mW | 140 mW | 5000 mW | 94-99% reduction |
| Reliability | >3B Operations | 10M Operations | 1-5M Operations | >1000x improvement |
| Switching Speed | <10 µs | 3-5 ms | 10-20 ms | >1000x improvement |
| Size/Channel Density | 6.2 mm3 2.5 x 2.5 x 1.0 mm BGA | 1280 mm3 16 x 8 x 10 mm SMT | 30,000 mm3 50 x 50 x 13 mm COAX | >99% reduction |
The MM5130 is the world’s first generally available high-power SP4T RF Ideal Switch.
It can handle 25 W forward power while providing ultra-low insertion loss. It has superior linearity from 26 GHz down to DC and performs more than 3 billion switching cycles.
The four switch channels are individually controllable by applying voltage to the corresponding RF GATE pin.
Access additional design information on the
Menlo Support Portal >
Top view
Bottom view
Bottom view
Profile view, featuring the through-glass-vias
The MM5130 on an evaluation kit board.
The MM5130 on an evaluation kit board.
• DC to 26 GHz Frequency Range
• 25 W (CW), 150 W (Pulsed) Max Power Handling
• Low On-State Insertion Loss: 0.3 dB @ 6.0 GHz
• High Linearity, IIP3 95 dBm Typical
• 25 dB Isolation @ 6.0 GHz / 45 dB Super-Port Mode
• High Reliability >3 Billion Switching Operations
• 2.5 mm x 2.5 mm WLCSP Package
• Defense and Aerospace
• Medical Equipment
• Test and Measurement
• Wireless Infrastructure
• Switched Filter Banks and Tunable Filters
• High Power RF Front Ends
• Antenna Tuning
• Low-Loss Switch Matrices & EM Relay Replacement
| EM (SMT) SPDT | EM (Coax) SPDT | Key Benefits | |
|---|---|---|---|---|
| Max Frequency | 26 GHz | 6 GHz | 18 GHz | |
| Insertion Loss | 0.4 dB @ 6GHz | 0.8 dB @ 6GHz | 0.2 dB @ 6GHz | |
| Isolation | 45 dB @ 6GHz | 25 dB | 70 dB @ 6GHz | |
| Power Handling | 25 W (CW) >150 W (Pulsed) | 50 W | 50 W - 100 W | |
| Linearity (IP3) | 95 dBm | 62 dBm | >1000x improvement | |
| Power Consumption | <0.08 mW | 140 mW | 5000 mW | 94-99% reduction |
| Reliability | >3B Operations | 10M Operations | 1-5M Operations | >1000x improvement |
| Switching Speed | <10 µs | 3-5 ms | 10-20 ms | >1000x improvement |
| Size/Channel Density | 5.6 mm3 2.5 x 2.5 x 0.9 mm BGA | 1280 mm3 16 x 8 x 10 mm SMT | 30,000 mm3 50 x 50 x 13 mm COAX | >99% reduction |
The MM5120 is the world’s first generally available high-power SP4T RF Ideal Switch.
This new innovative technology platform enables robust and highly reliable switches capable of >25 W CW power handling at 6.0 GHz. The MM5120 provides ultra-low insertion loss and superior linearity from DC to 18 GHz with >3 billion switching cycles.
The MM5120 features an integrated charge pump and driver circuit with SPI and GPIO interface control options.
Access additional design information on the
Menlo Support Portal >
MM5120 Switched Filter Bank
• DC to 18 GHz Frequency Range
• Integrated High-Voltage Driver
• 25 W (CW), 150 W (Pulsed) Max Power Handling
• Low On-State Insertion Loss: 0.4 dB @ 6.0 GHz
• High Linearity, IIP3 > 90 dBm
• > 25 dB Isolation @ 6.0 GHz
• Low Power Consumption <15mW
• High Reliability >3 Billion Switching Operations
• 5.2 mm x 4.2 mm LGA Package
• Defense and Aerospace
• Test and Measurement
• Wireless Infrastructure
• Switched Filter Banks and Tunable Filters
• High Power RF Front-Ends
• Low-Loss Switch Matrices
• RF EM Relay Replacement
• Antenna Tuning
• Antenna Beam Steering
• Digital Step Attenuators
| EM (SMT) SPDT | EM (Coax) SPDT | Key Benefits | |
|---|---|---|---|---|
| Max Frequency | 18 GHz | 6 GHz | 18 GHz | |
| Insertion Loss | 0.4 dB @ 6GHz | 0.8 dB @ 6GHz | 0.2 dB @ 6GHz | |
| Isolation | >25 dB @ 6GHz | 25 dB | 70 dB @ 6GHz | |
| Power Handling | 25 W (CW) >150 W (Pulsed) | 50 W | 50 W - 100 W | |
| Linearity (IP3) | >90 dBm | 62 dBm | 99% reduction in power consumption | |
| Power Consumption | <15 mW | 140 mW | 5000 mW | 90-99% reduction |
| Reliability | >3B Operations | 10M Operations | 1-5M Operations | >1000x improvement |
| Switching Speed | < 15 µs | 3-5 ms | 10-20 ms | >1000x improvement |
| Size/Channel Density | 33 mm3 5.2 x 4.2 x 1.5 mm LGA | 1280 mm3 16 x 8 x 10 mm SMT | 30,000 mm3 50 x 50 x 13 mm COAX | >99% reduction |
The MM5140 is the world’s highest performance generally available SP4T RF Ideal Switch module.
This new innovative technology platform enables robust and highly reliable switches capable of 25 W CW power handling at 3.0 GHz. The MM5140 provides ultra-low insertion loss and superior linearity from DC to 8 GHz with >3 billion switching cycles.
The MM5140 features an integrated charge pump and driver circuit with SPI and GPIO interface control options.
Access additional design information on the
Menlo Support Portal >
Top view
Bottom view
Bottom view
MM5140 on an evaluation kit board.
• DC to 8 GHz Frequency Range
• Integrated High-Voltage Driver
• 25 W (CW), 150 W (Pulsed) Max Power Handling
• Low On-State Insertion Loss: 0.5 dB @ 8.0 GHz
• High Linearity, IIP3 > 90 dBm
• > 25 dB Isolation @ 6.0 GHz
• Low Power Consumption <15mW
• High Reliability >3 Billion Switching Operations
• 5.2 mm x 4.2 mm LGA Package
• Defense and Aerospace
• Test and Measurement
• Wireless Infrastructure
• Switched Filter Banks and Tunable Filters
• High Power RF Front-Ends
• Low-Loss Switch Matrices
• RF EM Relay Replacement
• Antenna Tuning
• Antenna Beam Steering
• Digital Step Attenuators
| EM (SMT) SPDT | EM (Coax) SPDT | Key Benefits | |
|---|---|---|---|---|
| Max Frequency | 8 GHz | 6 GHz | 18 GHz | |
| Insertion Loss | 0.5 dB @ 8GHz | 0.8 dB @ 6GHz | 0.2 dB @ 6GHz | |
| Isolation | >25 dB @ 6GHz | 25 dB | 70 dB @ 6GHz | |
| Power Handling | 25 W (CW) >150 W (Pulsed) | 50 W | 50 W - 100 W | |
| Linearity (IP3) | >90 dBm | 62 dBm | 99% reduction in power consumption | |
| Power Consumption | <15 mW | 140 mW | 5000 mW | 90-99% reduction |
| Reliability | >3B Operations | 10M Operations | 1-5M Operations | >1000x improvement |
| Switching Speed | <15 µs | 3-5 ms | 10-20 ms | >1000x improvement |
| Size/Channel Density | 33 mm3 5.2 x 4.2 x 1.5 mm LGA | 1280 mm3 16 x 8 x 10 mm SMT | 30,000 mm3 50 x 50 x 13 mm COAX | >99% reduction |
